EXTRUSION OF FRC PRODUCTS

TECHNOLOGY

AND

PRACTICAL ASPECTS





HÄNDLE GMBH · MASCHINEN UND ANLAGENBAU · MÜHLACKER/ GERMANY



3eTECHNOLOGY

FOR



FIBER-REINFORCED CONCRETE

(FRC)



• PANELS

• FLOOR PLANKS

• DOOR JAMBS

• TRIMS & SPECIALS



Typical FRC extruded profiles using 3e Technology



3e - What does it mean?

e - for ecology

clean, environmental-friendly

e - for extrusion

hollow-core lightweight products, high output rates

€ - for €conomy

low capital investment and production costs



FRC Production Process

3e Technology



• Raw material dosing

• Weighing

• Batch Mixing (dry & wet)

• Continuous proportioning

• Extrusion

• Handling (wet side)

• Curing

• Handling (dry side)



• Grinding (if needed)

• Cut-to-length

• Strapping & storage



Material Compositions

The 3e Matrix can be made up of a combination

of different materials, e. g.

• cement, limestone powder, flyash

• fibers (a.r. glass fibers, cellulose and other natural or man-made fibers)

• silica, mica

• water

• additives

Händle can determine the ideal matrix by tests in lab and pilot plant.



3e Technology - The Händle Expertise



We assist in finding optimum composition by extensive lab extrusion tests, using clients‘ raw materials....



3e Technology - The Händle Expertise



... and in our pilot plant set-up by semi-industrial production runs



3e Technology - Production Part of dosing & weighing plant



3e Technology - Production



Dosing, weighing and mixing plant





3e Technology - Production



Overall view of dosing & mixing section





3e Technology - Production



Use of waste paper to produce cellulose fibers



3e Technology - Production



Pugging, Mixing & Extrusion



3e Technology - Production



Continuous Extrusion (single auger version)



3e Technology - Production



Continuous Extrusion using twin-auger machine (for wider panels)



3e Technology - Production



Continuous Extrusion of 2 columns (Special application profiles)



3e Technology - Production



Panels pre-cut to 6 m length



3e Technology - Production



Wet panels handled onto trays



3e Technology - Production



Semi-automatic handling & stacking process - entrance into curing tunnel (air curing)





3e Technology - Production





3e Technology - Production



Gang Saw

(cut to final length)



3e Technology - Production



Removal of panel stacks, strapping



3e Technology - Production



Indoor/ outdoor

storage - for final curing





3e FRC Product Properties

Specifications of typical 3E FRC Panel

Weight: 50 - 75 kg/m²

Compressive Strength: 15 - 20 N/mm²

Fire Resistance: 240 Minutes (Integrity)

Sound Insulation: 37 db (1000 Hz)

Water Absorption: 13 % (by weight)

Thermal Conductivity: 0,50 w/m.C



Pull-Out Test:

(using 18 mm hole diameter fixed with chemical anchor)



28,3 KN (pull-out load)



FRC 3e Panel Properties



FAST Quick installation, use of standard tools and techniques, easy service installation in vertical cores

As a result of hollow core profile, easy handling on



LIGHT



STRONG



site, reducing overall weight of construction

High loadbearing capacity and tensile strength, combined with non-combustibility





Reduced building costs due to low material costs, minimum waste and speedier construction with fewer trades

CLEAN Panel installation virtually dry, due to surface smoothness no need for surface rendering, precise

cut-to-length from factory



ENVIRONMEN- TAL-FRIENDLY



Minimum noise, dust and construction waste, use of recycled materials in manufacturing process.上海翻譯公司完成大自然介紹英文翻譯
